X6CrMoS17 Steel - Nr.1.4105
Ferritic Stainless Steel with Enhanced Machinability
It is similar to X3CrNb17, but the addition of sulfur improves its machinability, making it however less resistant to corrosion. Used for machining with chip removal, it is the low carbon version of the American AISI 430F type. It is also used because of its low magnetic hysteresis characteristics.
References and Comparable Standards
Standard Reference: EN 10088-3: 2014 (Hot-rolled and bright products)
| EUROPE | ITALY | GERMANY | FRANCE | UK | USA | ||
|---|---|---|---|---|---|---|---|
| EN 10088-3: 2005 |
(UNI 6900:71) |
(DIN 17440 - 85) |
(NF A 35-574-90) |
(BS 970 pt. 3 -91) |
AISI | ||
| Grade | N° | Werkstoff | N° | ||||
| X6CrMoS17 | 1.4105 | X10CrS17 | X6CrMoS17 | 1.4105 | Z8CF17 | - | AISI 430F |
Chemical Composition (Cast Analysis) (%)
| C / max | Si / max | Mn / max | P / max | S | Cr | Mo |
|---|---|---|---|---|---|---|
| 0,08 | 1,50 | 1,50 | 0,040 | 0,15÷0,35 | 16,0÷18,0 | 0,20÷0,60 |
Mechanical Properties - Rough Turned (1X) In The Annealed Condition
| Size (mm) | Hardness HB max* | Rp 0,2 (MPa) min | Rm (MPa) | A5 (%) min | Resistance to intergranular corrosion | |
|---|---|---|---|---|---|---|
| in the delivery condition | in the welded condition | |||||
| d≤100 | 200 | 250 | 430÷630 | 20 | NO | NO |
| * Only for guidance. | ||||||
Mechanical Properties - Cold Drawn (2H, 2B) And Ground Bars (2G) In The Solution Annealed Condition
| Size (mm) | Rp 0,2 (MPa) min | Rm (MPa) max | A5 (%) min* |
|---|---|---|---|
| d≤10 | 330 | 530÷780 | 7 |
| 10<d≤16 | 310 | 500÷780 | 7 |
| 16<d≤40 | 250 | 430÷730 | 12 |
| 40<d≤63 | 250 | 430÷730 | 12 |
| 63<d≤100 | 250 | 430÷630 | 20 |
| * Values valid only for size ≥5 mm. | |||
Mechanical Properties - Cold Drawn Wire And Coils (2H)
| Tensile strength levels | Rm (MPa) |
|---|---|
| +C 500 | 500÷700 |
| +C 650 | 650÷850 |
| +C 800 | 800÷1000 |
| +C 900 | 900÷1100 |
| Note: the desired tensile strength level shall be evaluated depending on diameter required. |
|
Mechanical Properties - Cold Drawn Wire And Coils In The Solution Annealed Condition (2D)
| Size | A (%) max | Rm (MPa) max |
|---|---|---|
| 0,10≤d≤0,20 | 10 | 900 |
| 0,20≤d≤0,50 | 15 | 850 |
| 0,50≤d≤1,00 | 15 | 850 |
| 1,00≤d≤3,00 | 15 | 800 |
| 3,00≤d≤5,00 | 15 | 750 |
| 5,00≤d≤16,00 | 20 | 700 |
| Note: If skin passed, Rm might be increased by up to 50 MPa. | ||
Working Temperatures Recommended
| Operation | °C |
|---|---|
| Hot forgings deformation | 800÷1100 |
| Annealing (air) | 750÷850 |
