(E335+S) Steel - Nr.(1.0060) (E335GC) - Nr.(1.0543)
What Is (E335+S)/(E335GC) Steel?
(E335+S) is a carbon steel based on E335 as defined in EN 10025-2. Sulfur improves machinability in chip-removal operations. The grade is not suitable for hardening heat treatments.
(E335+S)/(E335GC) Steel: References and Comparable Standards
Standard Reference: EN 10025-2: 2004 (Hot-rolled products) | EN 10277-2: 2008 (Bright products)
| Region | Standard | Grade | Werkstoff No. |
|---|---|---|---|
| Europe | EN 10025-2: 2004 EN 10277-2: 2008 |
(E335+S) | (1.0060) |
| Italy | (UNI 7070 - 72) | (Fe590+S) | - |
| Germany | (DIN 17100-80) | (St60-2+S) | (1.0060) |
| France | (NF A 35-501-83) | (A60-2+S) | - |
| UK | (BS 4360 - 90) | - | - |
| USA | ASTM A 29 | - | - |
Europe
StandardEN 10025-2: 2004
EN 10277-2: 2008
Grade(E335+S)
Werkstoff No.(1.0060)
Italy
Standard(UNI 7070 - 72)
Grade(Fe590+S)
Werkstoff No.-
Germany
Standard(DIN 17100-80)
Grade(St60-2+S)
Werkstoff No.(1.0060)
France
Standard(NF A 35-501-83)
Grade(A60-2+S)
Werkstoff No.-
UK
Standard(BS 4360 - 90)
Grade-
Werkstoff No.-
USA
StandardASTM A 29
Grade-
Werkstoff No.-
(E335+S)/(E335GC) Steel: Chemical Composition (Cast Analysis) (%)
(E335+S)/(E335GC) Steel: Mechanical Properties - As Rolled Condition
| Size (mm) |
Yield StrengthRp0.2 (MPa) min | Tensile StrengthRm (MPa) | ElongationA5 (%) min |
|---|---|---|---|
| d≤16 | 335 | 570-710 | 16 |
| 16<d≤40 | 325 | 570-710 | 16 |
| 40<d≤63 | 315 | 570-710 | 15 |
| 63<d≤80 | 305 | 570-710 | 14 |
| 80<d≤100 | 295 | 570-710 | 14 |
| 100<d≤150 | 275 | 550-710 | 12 |
| 150<d≤200 | 265 | 540-710 | 11 |
| 200<d≤230 | 255 | 540-710 | 11 |
(E335+S)/(E335GC) Steel: Mechanical Properties – Bright Steel
| Size (mm) |
as Rolled + Turned (+SH) |
Cold Drawn (+C) |
|||
|---|---|---|---|---|---|
| HardnessHB | Tensile StrengthRm (MPa) | Yield StrengthRp0.2 (MPa) min | Tensile StrengthRm (MPa) | ElongationA5 (%) min | |
| 5≤d≤10 | as Rolled + Turned (+SH)- | as Rolled + Turned (+SH)- | Cold Drawn (+C)540 | Cold Drawn (+C)700-1050 | Cold Drawn (+C)5 |
| 10<d≤16 | as Rolled + Turned (+SH)- | as Rolled + Turned (+SH)- | Cold Drawn (+C)480 | Cold Drawn (+C)680-970 | Cold Drawn (+C)6 |
| 16<d≤40 | as Rolled + Turned (+SH)169-211 | as Rolled + Turned (+SH)570-710 | Cold Drawn (+C)390 | Cold Drawn (+C)640-930 | Cold Drawn (+C)7 |
| 40<d≤63 | as Rolled + Turned (+SH)169-211 | as Rolled + Turned (+SH)570-710 | Cold Drawn (+C)340 | Cold Drawn (+C)620-870 | Cold Drawn (+C)8 |
| 63<d≤100 | as Rolled + Turned (+SH)169-211 | as Rolled + Turned (+SH)570-710 | Cold Drawn (+C)295 | Cold Drawn (+C)570-810 | Cold Drawn (+C)8 |
(E335+S)/(E335GC) Steel: Working Temperatures Recommended
| Operation | Temperature |
|---|---|
| Hot forgings deformation | 900-1150 °C |
| Soft annealing | 650-700 °C |
