16NiCr11 Steel
16NiCr11 Steel: High-Nickel Steel for Fatigue-Loaded Parts
Steel that originated in the automobile industry, no longer present in the international standards. Thanks to its high nickel content, it is used for pieces that are particularly subject to fatigue and vibrations.
16NiCr11 Steel: References and Comparable Standards
Standard Reference: UNI 5331-64
| EUROPE | ITALY | GERMANY | FRANCE | UK | USA | ||
|---|---|---|---|---|---|---|---|
| EN 10084: 2008 EN 10277-4: 2008 |
(UNI 7846-78) | (DIN 17210-84) | (NFA35-551-86) | (BS970 pt.1--96) | ASTM A 29 | ||
| Grade | N° | Werkstoff | N° | ||||
| (15NiCr13) | (1.5752) | 16NiCr11 | - | - | 14NC11 | - | - |
16NiCr11 Steel: Chemical Composition (Cast Analysis) (%)
| C | Si | Mn | P/max | S | Cr | Mo/max | Ni | Al |
|---|---|---|---|---|---|---|---|---|
| 0,12÷0,18 | 0,15÷0,40 | 0,30÷0,60 | 0,025 | 0,020÷0,035 | 0,60÷0,90 | 0,10 | 2,50÷3,00 | 0,020÷0,050 |
16NiCr11 Steel: Mechanical Properties - As Rolled Condition
| Hardness (HB) Treated to improve sherability (+S) |
Hardness (HB) Annealed to max. hardness requirements (+A) |
Hardness (HB) Treated to ferrite-pearlite structure and hardness range (+FP) |
|||
|---|---|---|---|---|---|
| ≤ 280 | ≤ 235 | ≥ 150 | ≤ 210 | ||
16NiCr11 Steel: Mechanical Properties – Bright Steel*
| Size (mm) |
+A**+ Turned (+A +SH) |
+A**+ Cold drawn (+A+C) |
FP***+ Turned (+FP +SH) |
FP***+ Cold drawn (+FP +C) | |||
|---|---|---|---|---|---|---|---|
| Hardness HB max |
Hardness HB max |
Hardness HB |
Hardness HB |
||||
| 5≤d≤10 | - | - | - | - | |||
| 10<d≤16 | - | 255 | - | 150÷220 | |||
| 16<d≤40 | 235 | 255 | 150÷210 | 150÷220 | |||
| 40<d≤63 | 235 | 255 | 150÷210 | 145÷215 | |||
| 63<d≤100 | 235 | 255 | 150÷210 | 145÷215 | |||
| *For reference only. **+A = Annealed to maximum hardness requirement. ***+FP = Treated to ferrite-perlite structure and hardness range. Note: For size <5 mm the mechanical properties may be agreed at the time of enquiry and order. |
|||||||
16NiCr11 Steel: Working Temperatures Recommended
| Operation | °C |
|---|---|
| Hot forgings deformation | 900÷1150 |
| Carburizing temperature | 880÷980 |
| Core quenching temperature | 840÷880 |
| Case quenching temperature | 780÷820 |
| Tempering | 150÷200 |
16NiCr11 Steel: Hardness Limits (Jominy Test)
| Limits of range | Hardness HRC at a distance from quenched end of test pieces (mm) | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1,5 | 3 | 5 | 7 | 9 | 11 | 13 | 15 | 20 | 25 | 30 | 35 | 40 | |||||||
| +H | Max | 48 | 46,5 | 44,5 | 43 | 41,5 | 40 | 39 | 37,5 | 35 | 32,5 | 31 | 29,5 | 28,5 | |||||
| Min | 39 | 36,5 | 34 | 32 | 30 | 28,5 | 27 | 26 | 23,5 | 21,5 | 19,5 | 18 | 17,5 | ||||||
