Rodinox® Steel
What Is Rodinox Steel?
Rodinox® is a patented low-nickel austenitic stainless steel wire developed by Rodacciai. Its mechanical properties and corrosion resistance are similar to those of 1.4301 (AISI 304). It can replace AISI 304 in many applications. Its austenitic structure is achieved by balancing lower nickel with higher manganese, copper, and nitrogen contents. Rodacciai supplies Rodinox® as drawn wire for household goods, appliances, grills, racks, bicycle spokes, and clotheslines. Rodinox Plus® bars are also available with improved machinability.
Rodinox Steel: References and Comparable Standards
| Region | Standard | Grade | Werkstoff No. |
|---|---|---|---|
| Europe | EN 10088-3: 2005 | - | - |
| Italy | (UNI 6900:71) | - | - |
| Germany | (DIN 1654-5: 89) | - | - |
| France | (NF A 35-574-90) | - | - |
| UK | (BS 3111 pt.2 -79) | - | - |
| USA | AISI | - | - |
Europe
StandardEN 10088-3: 2005
Grade-
Werkstoff No.-
Italy
Standard(UNI 6900:71)
Grade-
Werkstoff No.-
Germany
Standard(DIN 1654-5: 89)
Grade-
Werkstoff No.-
France
Standard(NF A 35-574-90)
Grade-
Werkstoff No.-
UK
Standard(BS 3111 pt.2 -79)
Grade-
Werkstoff No.-
USA
StandardAISI
Grade-
Werkstoff No.-
Rodinox Steel: Chemical Composition (Cast Analysis) (%)
| Carbon | %0,10 |
|---|---|
| Manganese | %5,00-9,00 |
| Silicon | %1,00 |
| Sulfur | %0,015 |
| Phosphorus | %0,045 |
| Chromium | %16,00-19,00 |
| Nickel | %3,00-6,00 |
| Copper | %1,00-4,00 |
| Nitrogen | %0,15-0,20 |
| *For Rodinox Plus bars, S = 0,015 - 0,030 | |
Rodinox Steel: Mechanical Properties - Cold Drawn Wire And Coils (2H)*
| Tensile Strength Levels | Tensile StrengthRm (MPa) |
|---|---|
| +C 600 | 600-800 |
| +C 700 | 700-900 |
| +C 800 | 800-1000 |
| +C 900 | 900-1100 |
| +C 1000 | 1000-1250 |
| +C 1100 | 1100-1350 |
| *For reference only. Note: the desired tensile strength level shall be evaluated depending on diameter required. |
|
Rodinox Steel: Mechanical Properties - Cold Drawn Wire And Coils In The Solution Annealed Condition (2D)*
| Size(mm) | Maximum ElongationA (%) max | Tensile StrengthRm (MPa) |
|---|---|---|
| 0,50≤d≤1,00 | 30 | 950 |
| 1,00≤d≤3,00 | 30 | 900 |
| 3,00≤d≤5,00 | 35 | 850 |
| 5,00≤d≤16,00 | 35 | 800 |
| *For reference only. Note: If skin passed, Rm might be increased by up to 50 MPa. |
||
Rodinox Steel: Mechanical Properties - Bars, Wire And Coils For Cold Heading*
| Size (mm) |
As Treated (+AT) or Peeled (+AT+PE) |
Cold Drawn (+AT +C) |
Cold Drawn + Solution annealed (+AT +C +AT) |
Cold Drawn + Solution annealed + Skin passed (+AT +C +AT +LC) |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Tensile StrengthRm (MPa) | Reduction of AreaZ (%) min | Tensile StrengthRm (MPa) | Reduction of AreaZ (%) min | Tensile StrengthRm (MPa) | Reduction of AreaZ (%) min | Tensile StrengthRm (MPa) | Reduction of AreaZ (%) min | ||||
| 2≤d≤5 | As Treated (+AT) or Peeled (+AT+PE)- | As Treated (+AT) or Peeled (+AT+PE)- | Cold Drawn (+AT +C)- | Cold Drawn (+AT +C)- | Cold Drawn + Solution annealed (+AT +C +AT)600 | Cold Drawn + Solution annealed (+AT +C +AT)68 | Cold Drawn + Solution annealed + Skin passed (+AT +C +AT +LC)650 | Cold Drawn + Solution annealed + Skin passed (+AT +C +AT +LC)63 | |||
| 5<d≤10 | As Treated (+AT) or Peeled (+AT+PE)590 | As Treated (+AT) or Peeled (+AT+PE)68 | Cold Drawn (+AT +C)740 | Cold Drawn (+AT +C)- | Cold Drawn + Solution annealed (+AT +C +AT)590 | Cold Drawn + Solution annealed (+AT +C +AT)68 | Cold Drawn + Solution annealed + Skin passed (+AT +C +AT +LC)640 | Cold Drawn + Solution annealed + Skin passed (+AT +C +AT +LC)63 | |||
| 10<d≤25 | As Treated (+AT) or Peeled (+AT+PE)590 | As Treated (+AT) or Peeled (+AT+PE)68 | Cold Drawn (+AT +C)740 | Cold Drawn (+AT +C)- | Cold Drawn + Solution annealed (+AT +C +AT)590 | Cold Drawn + Solution annealed (+AT +C +AT)68 | Cold Drawn + Solution annealed + Skin passed (+AT +C +AT +LC)- | Cold Drawn + Solution annealed + Skin passed (+AT +C +AT +LC)- | |||
| 25<d≤50 | As Treated (+AT) or Peeled (+AT+PE)590 | As Treated (+AT) or Peeled (+AT+PE)68 | Cold Drawn (+AT +C)- | Cold Drawn (+AT +C)- | Cold Drawn + Solution annealed (+AT +C +AT)- | Cold Drawn + Solution annealed (+AT +C +AT)- | Cold Drawn + Solution annealed + Skin passed (+AT +C +AT +LC)- | Cold Drawn + Solution annealed + Skin passed (+AT +C +AT +LC)- | |||
| * For reference only. | |||||||||||
Rodinox Steel: Working Temperatures Recommended
| Operation | Temperature |
|---|---|
| Hot forgings deformation | 900-1200 °C |
| Solution annealing (water, air) | 1000-1100 °C |
